Hazardous Area Products

Seen Joo Company offers a wide range of intrinsically safe and explosion proof products for applications in potentially explosive environment especially in the chemical, pharmaceutical, marine, ship-building, petrochemical, oil and gas industries.

We stock and supply ATEX, IECEX and GOST certified products of many international reputable brands from both Europe and Asia. Our company seeks to provide comprehensive solutions to all our customers for electrical enclosures, lightings and cable accessories installed in hazardous environment requiring constant and partial protection from flame and explosion.

Our trained product sales engineers and technical team will be delighted to assist you in selecting the most suitable and cost effective products for your projects.

Do feel free to contact us on your requirements.

Products' details are available below:

Product Type Description Applications

Stainless Steel Ex Enclosures
-top quality material for highest requirements
-more than 40 different version
-available in standard, flange and hinged versions
 Explosion protection:
II 2G/2D
Temperature classes
-T6(-20° to + 40°C)
-T5(-20° to +55°C)
-T4(-20° to +95°C)
-up to -55°C on request Certificates
Empty enclosures
PTB00 ATEX 1101U
Terminal enclosure
PTB 00 ATEX 1052
Note: Material specification is not relevant for EX approval(304/316)

Stainless Steel Ex Enclosures-PROTEX
 Explosion protection:
II 2G/2D
Temperature classes
-T6(-20° to + 40°C)
-T5(-20° to +55°C)
-T4(-20° to +95°C)
-up to -55°C on request Certificates
Empty enclosures
PTB00 ATEX 1101U
Terminal enclosure
PTB 00 ATEX 1052
Note: Material specification is not relevant for EX approval(304/316)

POLYSTER EX ENCLOSURE EX-FLANGE TYPE
 Explosion protection:
II 2G/2D
Temperature classes
-T6(-20° to + 40°C)
-T5(-20° to +55°C)
-up to -55°C on request Certificates
Empty enclosures
PTB00 ATEX 1061U
Terminal enclosure
PTB 00 ATEX 1002

POLYSTER EX- OKTABOX ENCLOSURES
 Explosion protection:
II 2G/2D
Temperature classes
-T6(-20° to + 40°C)
-T5(-20° to +55°C)
-up to -55°C on request Certificates
Empty enclosures
PTB00 ATEX 1061U
Terminal enclosure
PTB 00 ATEX 1002

POLYSTER EX-CABINET
 Explosion protection:
II 2G/2D
Temperature classes
-T6(-20° to + 40°C)
-T5(-20° to +55°C)
-up to -55°C on request Certificates
Empty enclosures
PTB00 ATEX 1061U
Terminal enclosure
PTB 00 ATEX 1002

ALUMINUM EX-ENCLOSURE
 Explosion protection:
II 2G/2D
Temperature classes
-T6(-20° to + 40°C)
-T5(-20° to +55°C)
-T4(-20° to +95°C)
-up to -55°C on request Certificates
Empty enclosures
PTB98 ATEX 3101U
Terminal enclosure
PTB 98 ATEX 1063


EJB
LOCAL STATION CONTROL		 FEAM FLOODLIGHTS FOR HALGON AND DISCHARGE LAMPS

MARINE GRADE COPPER FREE ALUMINUM BODY		 Explosion protection:
ATEX 94/9/EC
II 2 G Ex d IIB+H2 T6
II 2 G Ex d[ia/ib] IIB+H2 T6
II 2 D Ex Td A21 T85°C
IEC EX
II 2 G Ex d IIB+H2 T6
II 2 G Ex d[ia/ib] IIB+H2 T6
II 2 D Ex Td A21 T85°C
GOST-R(RTR /RTN)
1 Ex d IIB+H2 T6
1 Ex d [ja/ib] IIB + H2 T6
A21 TA 85°C
GOST-K
1 Ex d IIB +H2 T6
1 Ex d [Ia/ib] IIB +H2 T6
A21 TA 85°C


GUB		 FLAME PROOF ENCLOSURE

STAINLESS STEEL 316		 Explosion protection:
ATEX 94/9/EC
II 2 G Ex d IIB+H2 T6
II 2 G Ex d[ia/ib] IIB+H2 T6
II 2 D Ex Td A21 T85°C
IEC EX
II 2 G Ex d IIB+H2 T6
II 2 G Ex d[ia/ib] IIB+H2 T6
II 2 D Ex Td A21 T85°C
GOST-R(RTR /RTN)
1 Ex d IIB+H2 T6
1 Ex d [ja/ib] IIB + H2 T6
A21 TA 85°C
GOST-K
1 Ex d IIB +H2 T6
1 Ex d [Ia/ib] IIB +H2 T6
A21 TA 85°C


EJB 1NX
CONTROL,POWER AND SIGNALLING UNIT		 FLAME PROOF ENCLOSURE

STAINLESS STEEL 316		 Explosion protection:
ATEX BKI 08 ATEX 048
Ex d IIC T6-T5-T4
Ex Td A21 IP66 T85-T100-T135 °C
GOST-R (RTR)
Ex d [ia] IIC T6
Ex Td [iaD] A 21 IP66 T85°C
GGTN KAZ
Ex d [ibD] A21 IP66 T85° C
Ex d [ib] II C T6


EVAC		 FEAM MARINE FREE COPPER ALUMINUM LIGHT FITING FOR INCANDESCENT AND DISCHARGE LAMP
 Explosion protection:
ATEX 94/9/EC
II 2 G Ex IIC T6/T2
II 2 D Ex Td A21
T80°C/T290°C
GOST-R (RTR/RTN)
I Ex d IIC T6 X
DIP A 21 TA (80)°C
GOST -K
1 Ex d IIC T6 X
DIP A 21 TA (80)°C


EVF		 FEAM LIGHT FIXTURE FOR FLOURSCENT TUBE LAMP
 Explosion protection:
ATEX 94/9/EC
II 2 G Ex IIC T5/T4
II 2 D Ex tD A21
T100°C/T135°C
GOST-R (RTR/RTN)
I Ex d IIC T5/T4
DIP A 21 TA (100..135)°C
GOST -K
1 Ex d IIC T5/T4
DIP A 21 TA (100..135)°C


SFDQL/SFDN		 FEAM FLOOD LIGHT FOR DISCHARGE LAMP
 Explosion protection:
ATEX 94/9/EC
II 3 G Ex Nr T3
II 3 D Ex Dt A22
T 200°C IP66


SFDE		 FEAM FLOODLIGHTS FOR HALGON AND DISCHARGE LAMPS

MARINE GRADE COPPER FREE ALUMINUM BODY
 Explosion protection:
ATEX 94/9/EC
II 2 G Ex d/Ex de IIB T3/T2
II 2 D Ex t D A21 T200°C/T229°C
GOST-R (RTR/RTN)
1Ex de IIB T6 (T3..T2)
DIP A 21 TA (200..230) °C
GOST-K
1 Ex de IIB T6 (T3..T2)
DIP A 21 TA (200..230) °C
SKINTOP ®

MS-M/ MSR-M ATEX
SPECIAL BRASS GLAND FOR AREA WITH RISK FOR EXPLOSION
 Explosion protection:
ATEX 94/9/EC
IBExU01ATEX 1041 X
II 2G EEx II


A2F
A2F Un-ARMOURED, OUTER SHEATH SEAL CABLE GLAND		 Explosion protection:
IECEx BAS 11,0061X
Baseefa 11 ATEX EX0135X
CL.1,Div. 1 & 2,
Groups A,B,C,D/NEMA4, 4X
II2G Ex d II C & Ex e II IP 66


E1FW
E1FW Armoured, Outer & Inner Sheath Seal Cable Gland		 Explosion protection:
IECEx BAS 10,0057X
Baseefa 03atex0421X
CL.1,Div. 1 & 2,
Groups A,B,C,D/NEMA4, 4X
II2G Ex d II C & Ex e II IP 66
